๏ปฟHavenTechnik is an embedded consultancy with a propensity for #8BIT design and is PIC Micro-centric. We offer PLC-styled automation control solutions and #RF-based solutions. Our offering extends into development boards for the PIC #16F | #18F device families, and automation systems.

This document set is made available to assist customers in understanding the technical aspects of embedded engineering, and its associated discipline.

For marketing-related product information, please view the HavenTechnik main site

Click here to view the Product Catalogue๏ปฟ

๏ปฟ

๏ปฟ

PIC Development PCBs
RADIX
๏ปฟ

๏ปฟ

RADIX - Development Boards

The embedded development board has evolved from a DIY project to a professional and essential piece of equipment purchased from a reputable supplier.

The RADIX range of development boards are high-quality and reliable purchase. They will enable the rapid development of your application.

Using the RADIX development board means that you can focus on your coding and you have a reliable development board. There is no need to worry about loose connections or hardware issues.

Learn more about RADIX๏ปฟ.

PLC Styled Automation tools
SCALAE
๏ปฟ

SCALAE - Automation Systems

SCALAE*, is a product line of automation products based on the PIC Microcontroller. The MCU is integrated with hardware to ensure that they can interact with an industrialized or outside-world application.

With the inclusion of a Ladder development environment, the SCALAE units can be integrated into standard or traditional industrial environments.

Learn more about SCALAE๏ปฟ๏ปฟ

*Ladder or Stars

Actuate
Actuate
๏ปฟ

Actuate - System Expansion Modules

As your application expands, additional capabilities may be required not offered directly by SCALAE or ESCA. An actuate module extends capability by:

  • Ruggedise the application
  • Add analog capability when needed
  • Improve sensory capabilities
  • Improve communications capability

An Actuate module, would not normally have an MCU or intelligent control. If it does, it would be there to serve a specific function and not be reprogrammable, unless a software update were required.

Learn more about Actuate๏ปฟ๏ปฟ

APP Development

In an ever-evolving world, mobile apps play and will continue to play an ever-increasing role in applications. They round out and expand the application's reach and ease of user interaction. See the details of our product offering here, which is still in development.

Updated 10 Nov 2024
